Weather Station Specifications:
1. Outdoor temperature range: -40℃ to + 60℃, accuracy: ±0.3ºC
2. Indoor temperature range: 0℃ to + 60℃, accuracy: ±1ºC
3. Indoor Humidity range: 10% to 99%, accuracy: ±5%; Outdoor Humidity range: 1% to 99%, accuracy: ±3%
4. Barometric pressure range: 300 to 1100hpa , accuracy: ±3hpa
5. Rain volume: 0 – 9999mm
1) Resolution : 0.3mm (if rain volume < 1000mm)
2) 1mm (if rain volume > 1000mm)
accuracy: < 15 mm: +/- 1 mm, 15 mm to 9999 mm: +/- 7%
6. Wind speed Range: 0~50m/s
accuracy: 2 m/s ~ 10 m/s (± 0.3 m/s), 10 m/s ~ 50m/s (±10%)
7. Wind direction accuracy: 0 – 360º, accuracy: ± 10º
8. Sunlight index: 0 to 200,000 Lux, accuracy: ± 15%
9. UV index: 1 to 15+, accuracy:± 1 Levels
10. Integrated Outdoor Sensor transmission interval: 16s
11. Integrated Outdoor Sensor transmission range: 100m in open area (30m under most conditions)
12. Integrated Outdoor Sensor transmission frequency: 433MHz
13. Remote Thermo-hygrometer Sensor transmission range: 100m in open area (30m under most conditions)
14. Remote Thermo-hygrometer Sensor transmission frequency: 433MHz
15. Wifi standard: 802.11 b/g/n
16. Wifi frequency: 2.4GHZ
16. Line of sight of Wifi transmission: 20m
Weather Station Power consumption:
1) Display Console: 3 x AAA 1.5V Alkaline or Lithium batteries (not included)
2) Integrated Outdoor Sensor: 3 x AA 1.5V alkaline batteries or Lithium batteries (not included)
The batteries provide backup power when there is limited solar energy.
3) Remote Thermo-hygrometer Sensor: 2 x AAA 1.5V Alkaline or Lithium batteries (not included)
3) Power Adaptor: 5.9V/0.5A
Weather Station Dimensions:
Display Console (LxHxW): 215x158x22mm (8.47×6.22×0.87inch)
LCD Dimensions (LxW): 170×125 mm (6.7×4.9inch)
Integrated Outdoor Sensor(FT019T): 330x280x150mm (13x11x5.9 inch)
Remote Thermo-Hygrometer Sensor: 110x45X21mm (4.33×1.77×0.83inch)
Weather Station Packages:
1 x Indoor Display Console
1 x Solar Integrated Outdoor Sensor (FT019T)
1 x Remote Thermo-Hygrometer Sensor (FT007TH)
1 x Mounting Bracket Back Plate
1 x Mounting Pole + 1 x Foot Mounting
1 x English Manual
1 x Power Adapter( Console use only)
Spare parts: Pole mounting nuts and bolts
